8 Channel Compact 1U Lite Network Video Recorder
>H.264+/H.264 codec decoding
>Max 80Mbps incoming bandwidth
>Up to 6Mp resolution preview&playback
>HDMI/VGA simultaneous video output
>3D intelligent positioning with Dahua PTZ camera
dahua/داهوا
NVR2108HS-S2
| System | ||
| Main Processor | Intel Dual-core Processor | |
| Operating System | Embedded LINUX | |
| Environmental | ||
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa | |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH | |
| Video Detection and Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering | |
| Display | ||
| Interface | 1 HDMI, 1 VGA | |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |
| Multi-screen Display | 1/4/8/9 | |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Recording | ||
| Compression | H.265/H.264/MJPEG | |
| Resolution | 6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc. | |
| Record Rate | 80Mbps | |
| Bit Rate | 16Kbps ~ 20Mbps Per Channel | |
| Record Mode | Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop | |
| Playback and Backup | ||
| Playback | 1/4/8 | |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
| Backup Mode | USB Device/Network | |
| Third-party Support | ||
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more | |
| Audio and Video | ||
| IP Camera Input | 8 Channel | |
| Two-way Talk | 1 Channel Input, 1 Channel Output, RCA | |
| Electrical | ||
| Power Supply | Single, DC12V/4A | |
| Network | ||
| Interface | 1 RJ-45 Port (1000M) | |
| Ethernet Port | 1 Independent 100Mbps Ethernet Port | |
| PoE | 8 ports (IEEE802.3at/af) | |
| Network Function | HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) | |
| Optical Fiber Interface | N/A | |
| Max. User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 2.4, CGI Conformant | |
| Storage | ||
| Internal HDD | 1 SATA III Port, up to 6TB capacity for each HDD | |
| HDD Mode | Single | |
| eSATA | N/A | |
| Auxiliary Interface | ||
| USB | 2 ports (1 Rear USB2.0, 1 Front USB2.0) | |
| Construction | ||
| Dimensions | Compact 1U, 260mm×224.9mm×47.6mm (10.2" x 8.9" x 1.9") | |
| Gross Weight | 10.5kg (23.1 lb) | |
| Certifications | ||
| CE1 | EN55022, EN55024, EN50130-4, EN60950-1 | |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 | |
