32 Channel Ultra 4K H.265 Network Video Recorder
> Intel Processor
> Max 32 IP Camera Inputs
> Max 384Mbps Incoming Bandwidth
> Up to 12MP Resolution for Preview and Playback
> Supports RAID 0/1/5/6/10/50/60
> Smart Tracking and Intelligent Video
dahua/داهوا
NVR608-32-4KS2
| System | ||
| Main Processor | Intel Dual-core Processor | |
| Operating System | Embedded LINUX | |
| Environmental | ||
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa | |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH | |
| Video Detection and Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering | |
| Alarm input | 16 Channel, Low Level Effective, Green Terminal Interface | |
| Relay Output | 8 Channel, NO/NC Programmable, Green Terminal Interface | |
| Tracking Trigger Event | Zoom, Tracking, Recording, Preset, Snapshot, Alarm, etc. | |
| Display | ||
| Interface | 2 HDMI (up to 3840 x 2160 , Different Source), 1 VGA | |
| Resolution | 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 | |
| Multi-screen Display | 1st Screen: 1/4/8/9/16/25/36 2nd Screen: 1/4/8/9/16 | |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Recording | ||
| Compression | H.265/H.264/MJPEG | |
| Resolution | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc. | |
| Record Rate | 384Mbps | |
| Bit Rate | 16Kbps ~ 20Mbps Per Channel | |
| Record Mode | Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop | |
| Playback and Backup | ||
| Playback | 128 Mbps in Raid 5 Mode; 64 Mbps in single HDD Mode | |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
| Backup Mode | USB Device/Network/eSATA Device | |
| Third-party Support | ||
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more | |
| Audio and Video | ||
| IP Camera Input | 32 Channel | |
| Two-way Talk | 1 Channel Input, 1 Channel Output, RCA | |
| Electrical | ||
| Power Supply | AC100V ~ 240V, 50 ~ 60 Hz | |
| Power Consumption | <20W (Without HDD) | |
| Network | ||
| Interface | 2 RJ-45 Ports (10/100/1000Mbps) | |
| Ethernet Port | 2 Ethernet Ports Joint Working or 2 Independent 1000Mbps Ethernet Ports | |
| PoE | N/A | |
| Network Function | HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) | |
| Optical Fiber Interface | N/A | |
| Max. User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 2.4, CGI Conformant | |
| Storage | ||
| Internal HDD | 8 SATA Ports, up to 8 TB capacity for each disk | |
| HDD Mode | Single, Raid 0/1/5/6/10/50/60 (Support Global HDD Hot-spare) | |
| eSATA | 1 eSATA Port (Please contact technical engineer to confirm the compatible device) | |
| SAS | N/A | |
| Auxiliary Interface | ||
| USB | 4 USB Ports (2 USB 2.0 , 2 USB 3.0 ) | |
| RS232 | 1 Port, for PC Communication and Keyboard | |
| RS485 | 1 Port, for PTZ Control | |
| Construction | ||
| Dimensions | 2U, 440mm x 451.08mm x 94.85mm (17.3" x 17.8" x 3.7") | |
| Gross Weight | 10.5kg (23.1 lb) | |
| Certifications | ||
| CE1 | EN55022, EN55024, EN50130-4, EN60950-1 | |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 | |
