SD49225T-HN

2MP 25x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 25x optical zoom
> Starlight technology
> Support H.265&H.264 Triple-streams encoding
> Max. 50/60fps@1080P, 25/30/50/60fps@720P
> IVS
> Support PoE+
> IR distance up to 100m

> IP66

dahua/داهوا

SD49225T-HN



DORI Distance
Detect Observe Recognize Identify
1613m(5259ft) 646m(2119ft) 323m(1060ft) 161m(528ft)
Interface
Audio Interface 1 channel in
Alarm 2/1
Camera
IR On/Off Control Auto/Manual
Scanning System Progressive
Environmental
Vandal Resistance N/A
Video
Compression H.265/H.264 / MJPEG
Privacy Masking Up to 24 areas
Flip 180°
Digital Zoom 16x
Noise Reduction Ultra DNR (2D/3D)
White Balance Auto, ATW, Indoor, Outdoor, Manual
Backlight Compensation BLC / HLC / WDR (120dB)
Day/Night Auto(ICR) / Color / B/W
Streaming Capability 3 Streams
Lens
Optical Zoom 25x
PTZ
Pan/Tilt Range Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°,auto flip 180°
Manual Control Speed Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s
Preset Speed Pan: 240° /s; Tilt: 200° /s
Presets 300
PTZ Mode 5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Speed Setup Human-oriented focal Length/ speed adaptation
Power up Action Auto restore to previous PTZ and lens status after power failure
Idle Motion Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Protocol DH-SD, Pelco-P/D (Auto recognition)
Electrical
Power Supply DC 12V/3A
Construction
Dimensions Φ160(mm) x 295(mm)
Net Weight 4kg(8.82lb)
Gross Weight 4.2kg(9.26lb)
Certifications
Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-1+CAN/CSA C22.2,No.60950-1
